USPTO Patent Application — Noah ArkCore Hybrid Propulsion System
United States Patent and Trademark Office — Utility Patent Application
Hybrid Quantum Vacuum Energy Extraction & Antimatter Confinement Propulsion System
with Embedded Quantum Error Correction Control
Type: Non-Provisional Application
Status: Filing Pending
App. No.: [USPTO Assigned]
Filing Date: [To Be Assigned]
Docket: NK2-NAQTL-2026-P001
NAQTL Seal
Applicant
Legal EntityAddressCountryForm
Noah's Ark Quantum Tech Lab142 Avenue René Cassin, 81100 Castres, FranceFrance 🇫🇷SAS
Inventors
NameResidenceCitizenshipTechnical ContributionORCID
Noah Kouadri KhazarCastres, FranceFrenchSystem architecture · Casimir physics · Antimatter confinement design0009-0001-5332-9083
Adam KouadriCastres, FranceFrenchAI optimisation · Quantum control algorithms · Embedded systems—
Sarah KouadriCastres, FranceFrenchEcological design · Materials lifecycle · Thermal management—
[0001] This application claims priority under 35 U.S.C. §119(e) to U.S. Provisional Application No. 63/XXX,XXX and under 35 U.S.C. §119(a) to French Application No. FR 2026/XXXXX. Both are incorporated herein by reference in their entirety.
Background of the Invention
Field of the Invention

[0004] The present invention relates generally to advanced spacecraft propulsion systems, and more particularly to a hybrid propulsion architecture combining quantum vacuum energy extraction, antimatter confinement and annihilation, and quantum error correction (QEC) based real-time control for high-specific-impulse, high-thrust-density space propulsion and terrestrial energy generation applications.

Description of Related Art

[0005] Conventional spacecraft propulsion relies on chemical combustion of propellants (hydrazine, liquid oxygen/kerosene, liquid hydrogen/oxygen) or electric propulsion (ion engines, Hall-effect thrusters, magnetoplasmadynamic thrusters). These systems are fundamentally limited by the Tsiolkovsky rocket equation, requiring exponential propellant mass for high delta-V missions. Specific impulses (Isp) range from 300–450 s for chemical systems to 1,500–3,000 s for electric systems.

[0007] Antimatter propulsion has been theorized since the 1950s. The annihilation of protons and antiprotons (p + p̄) converts 100% of rest mass to energy (E = mc²), yielding specific energies of 9×10¹³ J/g for proton-antiproton. Practical implementation faces three fundamental challenges: (a) Production — current antiproton yield at CERN is ~10⁷ p̄/year; (b) Confinement — charged antimatter must be stored in Penning traps with lifetimes limited by vacuum quality; (c) Thrust conversion — efficient conversion of annihilation products to directed thrust requires complex magnetic nozzle systems.

[0009] Zero-point energy (ZPE) extraction via the Casimir effect has been theoretically studied and experimentally demonstrated at nanometer scales. The dynamical Casimir effect (DCE) in non-stationary systems and analogue Hawking radiation in Bose-Einstein condensates suggest energy extraction from quantum vacuum fluctuations is physically possible under specific conditions. Recent metamaterial-enhanced Casimir systems and analogue dynamic Schwinger effect demonstrations (ACS Photonics, 2025; TechRxiv, 2025) have advanced the field.

[0011] No prior art combines: (i) quantum vacuum energy extraction via metamaterial-enhanced dynamical Casimir effect; (ii) antimatter confinement in integrated Penning micro-traps; (iii) hybrid energy transduction via magnon-photon coupling and Josephson junction arrays; and (iv) real-time quantum error correction control using embedded neural networks for autonomous optimisation of all subsystems simultaneously.

Brief Summary of the Invention

[0012] The present invention provides a hybrid propulsion system and method that overcomes the limitations of prior art by synergistically combining four technological pillars:

Four Pillars of Innovation

I. Metamaterial-Enhanced DCR: Extracts energy from quantum vacuum fluctuations via controlled THz-frequency modulation of boundary conditions using piezoelectric actuation of nanostructured plasmonic surfaces.

II. Integrated Penning Micro-Trap Array (IPMTA): Confines antiprotons and/or positrons using superimposed static magnetic and electric fields on a 10 mm × 10 mm semiconductor chip with 64 independent sites.

III. Hybrid Transduction Chain (HTC): Converts extracted ZPE and antimatter annihilation energy into directed thrust via YIG magnon-photon coupling, Josephson junction AC-DC conversion, and quantum Stirling heat engines.

IV. Quantum Error Correction Controller (QECC): Embedded NV-center diamond qubits with neural network-based surface-code decoding maintain subsystem coherence and optimise thrust vectoring in real time.

[0017] The invention achieves theoretical specific impulses exceeding 106 seconds with thrust-to-power ratios of 10–100 N/MW, enabling rapid transit to Mars (≤45 days), outer planet missions (≤2 years to Saturn), and ultimately interstellar precursor missions.

Drawings
FIG. 1 Complete Noah ArkCore System 10 — Schematic Overview with Thermal Stratification
QECC 60 NV-Center Diamond Surface Code d=7 T = 10 mK Fidélité >99.2% MDCR 40 Casimir Resonator Ti/SiO₂/Au/Graphene T = 10 mK IPMTA 30 Penning Micro-Traps 64 sites · 10 mm² T = 10 mK HTC 50 YIG · Josephson · Stirling T = 10 mK → 300 K η > 90% MSCS 70 Cryogenic System 4 K – 300 K ³He/⁴He · N₂ ASM 20 Antimatter Source ²²Na / CERN 10⁶ e⁺/p̄ 4 K – 300 K EAIOE 80 Neural Net AI TF Quantum THRUST e⁺/p̄ ZPE Annih. NOAH ARKCORE SYSTEM 10 Spacecraft Installation · Thermal Stratification View Energy flow Control signal 100 mm
FIG. 1 — Schematic perspective of the complete Noah ArkCore hybrid propulsion system 10 installed in a spacecraft hull 12. Thermal stratification is shown by the radial colour gradient (deep blue = 10 mK core; red periphery = 300 K). Solid red arrows indicate energy flows; blue dashed arrows indicate control/feedback signals. Seven principal subsystems (20–80) are labelled with their reference numerals, operating temperature ranges, and key parameters.
FIG. 2 System Architecture Block Diagram — Energy & Control Signal Paths
ASM 20 ²²Na Radioisotope / CERN Antiproton e⁺/p̄ IPMTA 30 Penning Micro-Trap 64 sites · 10 mK Annih. HTC 50 YIG · Josephson · Stirling Transduction Chain THRUST I_sp >10⁶ s MDCR 40 Casimir Resonator ZPE Extraction ZPE QUANTUM CONTROL QECC 60 NV-Center Surface Code EAIOE 80 GNN Decoder · TF Quantum Control MSCS 70 Cryogenic System 10 mK → 300 K → Space Energy / mass flow Control / feedback
FIG. 2 — System architecture block diagram. Solid red arrows denote energy/mass flows; blue dashed arrows denote bidirectional control and feedback signals. The quantum control sub-block (dashed purple border) encompasses both the QECC 60 surface-code processor and the EAIOE 80 neural network decoder, which together optimise all subsystems in real time at <1 µs latency.
TABLE 1 Principal Subsystems — Reference Numbers, Functions, and Mass
Ref.Subsystem NamePrimary FunctionOperating TMass (kg)
20Antimatter Source Module (ASM)Production / storage of antiprotons & positrons via ²²Na or CERN interface4 K – 300 K35
30Integrated Penning Micro-Trap Array (IPMTA)Confinement & manipulation of charged antimatter (64 independent sites)10 mK – 4 K12
40Metamaterial Dynamical Casimir Resonator (MDCR)Extraction of energy from quantum vacuum fluctuations via THz piezo-modulation10 mK – 1 K8
50Hybrid Transduction Chain (HTC)Conversion of ZPE & annihilation energy to directed thrust via YIG·Josephson·Stirling stages10 mK – 300 K15
60Quantum Error Correction Controller (QECC)Real-time stabilisation of all quantum subsystems using NV-center surface code10 mK – 4 K5
70Multi-Stage Cryogenic System (MSCS)Thermal management from 10 mK to 300 K; heat rejection to space via radiators4 K – 300 K120
80Embedded AI Optimisation Engine (EAIOE)Graph Neural Network decoder for QEC + adaptive thrust optimisation4 K – 300 K3
TOTAL SYSTEM MASS~198 kg
FIG. 3 MDCR 40 — Cross-Sectional Layer Stack & Piezoelectric Actuation
2.5 mm
SUBSTRATE 52 — Titanium Grade 2 (structural)
200 nm
INSULATING LAYER 54 — SiO₂ (PECVD, 200 nm)
100 nm
BOTTOM ELECTRODE 56 — Au (e-beam evaporation)
~50 nm
ACTIVE STACK 58 — [HfO₂ 10 nm / Graphene 0.34 nm] × 10
~150 nm
TOP METASURFACE 60 — Bi₂Se₃ + Au Nanopillar Array (200 nm period)
2 μm
PIEZOELECTRIC ACTUATOR 62 — PZT Thin Film
—
INTERDIGITATED ELECTRODES 64 — Au (IDT contacts)
d(t) = d₀ + δd · sin(Ωt), where d₀ = 100 nm, δd/d₀ ≈ 0.1, Ω ≈ 2ωcav ≈ 1–10 THz
FIG. 3 — Cross-sectional view of MDCR 40 from substrate to top surface (not to scale). The active stack 58 consists of 10 alternating layers of HfO₂ and single-layer graphene. The piezoelectric actuator 62 (PZT) dynamically modulates the plate separation d(t) at the cavity resonance frequency Ω, driving the dynamical Casimir effect. Total fabricated thickness (excluding substrate): ~2.5 μm.
FIG. 4 IPMTA 30 — 8×8 Penning Micro-Trap Array Chip Top View
CMOS MULTIPLEXING 36
MPX
1,1
1,2
1,3
1,4
1,5
1,6
1,7
1,8
MPX
MPX
2,1
2,2
2,3
2,4
2,5
2,6
2,7
2,8
MPX
MPX
3,1
3,2
3,3
3,4
3,5
3,6
3,7
3,8
MPX
MPX
4,1
4,2
4,3
4,4
4,5
4,6
4,7
4,8
MPX
MPX
5,1
5,2
5,3
5,4
5,5
5,6
5,7
5,8
MPX
MPX
6,1
6,2
6,3
6,4
6,5
6,6
6,7
6,8
MPX
MPX
7,1
7,2
7,3
7,4
7,5
7,6
7,7
7,8
MPX
MPX
8,1
8,2
8,3
8,4
8,5
8,6
8,7
8,8
MPX
BOND PADS 35 — 48 contacts

Substrate 32: Si · 10 mm × 10 mm × 0.5 mm  |  Pitch: 1.2 mm  |  Trap sites 34: 64  |  B = 1–3 T

FIG. 4 — Top plan view of IPMTA 30. Green cells represent active Penning trap sites 34 (8×8 array). Gold cells represent CMOS multiplexing circuitry 36 surrounding the array. Each trap site 34 has an 80 μm ring electrode radius (r₀) and 100 μm endcap separation (2z₀), with individual voltage control via the CMOS bus. Vacuum: <10⁻¹⁰ mbar.
FIG. 5 IPMTA 30 — Single Trap Site 34 Cross-Section with Field Configuration
MAGNET 42 / 44 · B = 1 – 3 T (NdFeB or NbTi) B ↑ ENDCAP 40a · +V₀/2 RF 46 RF 46 RING 38 · V_ring e⁺ cyclotron ENDCAP 40b · −V₀/2 2r₀ = 160 μm 2z₀ = 100 μm V(r,z) = V₀/(2d²) × (r² − 2z²)
FIG. 5 — Cross-section of a single Penning trap site 34. Three vertical B-field lines (blue) indicate the solenoidal magnetic field. The gold ring electrode 38 and two endcaps 40a/40b create the electrostatic quadrupole well V(r,z). An antiparticle (e⁺ shown in orange) undergoes circular cyclotron motion at radius r_c. RF injection ports 46 allow sideband cooling. Key dimensions: r₀ = 80 μm, z₀ = 50 μm.
TABLE 3 IPMTA 30 — Key Operating Parameters
ParameterValueUnitPhysical Significance
Magnetic field B1.0 – 3.0TCyclotron frequency f_c = 27.9 – 83.8 GHz
Ring voltage V₀1.0 – 10.0VAxial frequency f_z = 10 – 100 MHz
Trap depth1.0 – 10.0eVConfines particles at T equivalent to 10⁵ K
Vacuum pressure<10⁻¹⁰mbarPositron lifetime >1000 s
Number of trap sites64—8×8 array, individually addressable
Loading efficiency>10%From moderated beam injection
Operating temperature10mKDilution refrigerator stage, ³He/⁴He
FIG. 6 HTC 50 — Hybrid Transduction Chain: YIG → Josephson → Stirling → Nozzle
STAGE 50A YIG Sphere 72 YIG Ø 1 mm Cavity 74 (TE₀₁₁) g/2π > 50 MHz μwave STAGE 50B Josephson Array 76 ×1000 junctions Al/AlOₓ/Al η > 90% DC V STAGE 50C Quantum Stirling 77 ErNi / Gd 78 η ≥ η_Carnot MECHANICAL OUTPUT → Nozzle 82 50–80% η >90% η 40–60% η 30–50% η Hybrid Transduction Chain (HTC) 50
TABLE 6 — HTC Performance Parameters
StageInputOutputEfficiencyKey Material
50A — YIGZPE photons (GHz)Coherent magnons50–80%Y₃Fe₅O₁₂ (YIG)
50B — JosephsonMagnon microwave fieldDC voltage>90%Al/AlOₓ/Al
50C — StirlingDC electrical powerMechanical work40–60%ErNi, Gd
50D — NozzleParticle/photon momentumDirected thrust30–50%NbTi, W-Cu
FIG. 6 — Schematic of the Hybrid Transduction Chain 50 showing four cascaded conversion stages. Energy flows left-to-right (solid red). Stage 50A converts quantum photons to coherent magnons in a YIG sphere 72 inside a TE₀₁₁ microwave cavity 74 with coupling strength g/2π >50 MHz. Stage 50B uses 1000 Josephson junctions in an Al/AlOₓ/Al array 76 for AC-DC rectification (η >90%). Stage 50C is a quantum Stirling heat engine using ErNi/Gd magnetocaloric materials 78. Stage 50D is a magnetic nozzle 82 delivering directed thrust.
FIG. 7 QECC 60 — NV-Center Array, Surface Code Layout & GNN Decoder Architecture
NV ARRAY 90 7×7 · 2 μm pitch · Diamond 49 physical qubits SURFACE CODE 92 Distance d = 7 X stabilizer Z stabilizer data qubit 1 logical qubit GNN DECODER 96 Graph Neural Network · 3 layers Latency <1 μs · 10⁶ syndromes/s qLDPC 94 — Alternative [[144, 12, 12]] Bicycle code Overhead ≈5× smaller than surface QECC PERFORMANCE TARGETS Logical error rate: <10⁻¹⁵ per cycle Physical qubit fidelity: >99.2% gate F Operating temperature: 10 mK (dilution) QEC decoder latency: <1 μs (GNN)
FIG. 7 — QECC 60 block diagram. The NV-center qubit array 90 (7×7 = 49 physical qubits) encodes one logical qubit via the d=7 surface code 92. X-type stabilisers (orange) and Z-type stabilisers (blue) are measured continuously. Syndrome measurements feed the Graph Neural Network decoder 96 operating at <1 μs latency. An alternative qLDPC encoding 94 ([[144,12,12]] bicycle code) offers 5× reduced overhead. Bottom bar shows key performance targets.
Claims

The invention claimed is:

CLAIM 1 — Independent
A hybrid propulsion system comprising: (a) a metamaterial dynamical Casimir resonator (MDCR) configured to extract energy from quantum vacuum fluctuations by modulating electromagnetic boundary conditions at terahertz frequencies; (b) an integrated Penning micro-trap array (IPMTA) configured to confine at least one species of charged antimatter selected from the group consisting of antiprotons and positrons; (c) a hybrid transduction chain (HTC) operatively coupled to both said MDCR and said IPMTA, configured to convert extracted vacuum energy and antimatter annihilation energy into directed thrust; and (d) a quantum error correction controller (QECC) operatively coupled to said MDCR, said IPMTA, and said HTC, configured to maintain quantum coherence of said system using real-time surface-code error correction.
CLAIM 2 — Dependent on Claim 1
The system of claim 1, wherein said MDCR comprises: (i) a titanium substrate; (ii) an active stack comprising alternating layers of hafnium oxide (HfO₂) and graphene; (iii) a bismuth selenide (Bi₂Se₃) topological insulator metasurface with gold nanopillar array having period of approximately 200 nm; and (iv) a lead zirconate titanate (PZT) piezoelectric actuator configured to modulate plate separation d(t) = d₀ + δd·sin(Ωt) where Ω ≈ 2ω_cav.
CLAIM 3 — Dependent on Claim 1
The system of claim 1, wherein said IPMTA comprises a silicon substrate of approximately 10 mm × 10 mm carrying a plurality of Penning trap sites arranged in an 8×8 array, each trap site having a ring electrode radius r₀ of approximately 80 μm and endcap separation 2z₀ of approximately 100 μm, with individual site control provided by CMOS multiplexing circuitry and operating at temperatures at or below 10 mK.
CLAIM 4 — Dependent on Claim 1
The system of claim 1, wherein said HTC comprises three cascaded stages: (a) a first stage comprising a yttrium iron garnet (YIG) sphere of approximately 1 mm diameter magnetically coupled to a microwave cavity with coupling strength g/2π exceeding 50 MHz; (b) a second stage comprising an array of at least 100 superconducting Josephson tunnel junctions in an Al/AlOₓ/Al material system for AC-to-DC conversion with efficiency exceeding 90%; and (c) a third stage comprising a quantum Stirling heat engine using magnetocaloric materials selected from erbium nickel alloy (ErNi) and gadolinium (Gd).
CLAIM 5 — Dependent on Claim 1
The system of claim 1, wherein said QECC comprises: (a) an array of nitrogen-vacancy (NV) center qubits in a type-IIa diamond substrate; (b) a surface code implementation with code distance d ≥ 7 providing logical error rates below 10⁻¹⁵ per code cycle; and (c) a graph neural network (GNN) decoder configured to process syndrome measurements at a rate exceeding 10⁶ measurements per second with decoding latency below 1 microsecond.
CLAIM 6 — Independent (Method)
A method for hybrid space propulsion comprising: extracting energy from quantum vacuum fluctuations by dynamically modulating at terahertz frequencies boundary conditions of a metamaterial Casimir resonator structure; simultaneously confining charged antimatter in a Penning micro-trap array at temperatures below 100 mK and pressures below 10⁻¹⁰ mbar; transducing the extracted vacuum energy and annihilation energy through at least three cascaded conversion stages to produce directed thrust; and applying real-time quantum error correction using surface-code stabiliser measurements and neural-network decoding to maintain coherence of each operational stage.
CLAIMS 7–15
Claims 7–15 are directed to: multi-stage cryogenic system configurations (claim 7); embedded AI optimisation engine using TensorFlow Quantum (claim 8); antimatter source configurations including radioisotope ²²Na and CERN/BASE-STEP interface (claim 9); magnetic nozzle thrust vectoring (claim 10); use in interplanetary propulsion achieving Mars transit in ≤45 days (claim 11); use in satellite station-keeping (claim 12); use in terrestrial energy generation (claim 13); spacecraft hull integration and thermal management (claim 14); and method of manufacturing the metamaterial Casimir resonator layer stack (claim 15).
Abstract
Abstract of the Disclosure

A hybrid propulsion system (10) and associated methods combine four synergistic technological pillars to overcome fundamental limits of prior-art spacecraft propulsion. A metamaterial dynamical Casimir resonator (MDCR 40) extracts energy from quantum vacuum fluctuations by piezoelectrically modulating Ti/SiO₂/Au/HfO₂/Graphene/Bi₂Se₃ nanostructures at terahertz frequencies. An integrated Penning micro-trap array (IPMTA 30) confines up to 10⁶ antiprotons or positrons on a 10 mm × 10 mm silicon chip with 64 independently addressable sites at 10 mK and pressures below 10⁻¹⁰ mbar. A hybrid transduction chain (HTC 50) converts extracted energy through cascaded YIG magnon-photon coupling, Josephson junction AC-DC rectification (>90% efficiency), and quantum Stirling heat engine stages to produce directed thrust. All subsystems are controlled in real time by an embedded quantum error correction controller (QECC 60) employing NV-center diamond qubits arranged in a surface code of distance d=7, decoded by a graph neural network at latency below 1 µs. The system achieves theoretical specific impulses exceeding 10⁶ seconds, enabling Mars transit in ≤45 days, with zero operational carbon emissions.
